Years ago, I worked on reimplementing1 some Python code in Rust (yet again), and this time I needed to adapt Python’s dynamic capabilities (aka __getattr__) to the strict and compiled world of Rust.

After some deliberation, and armed with the serde (de)serialization crate, I set out to do just that.

So if you ever wondered what tricks Rust can learn from Python, and if serde can be used for reflection (please go along with me here), then the answer is very much yes!
Let me show you how, and also why.

Note: I’ll try to keep this somewhat approachable to Python programmers with only passing experience in Rust, it’ll be fun. 🦀🐍

Rick and Morty - Let's go. In and out. 20 minutes adventure, with complex Rust code with many types in the wormhole

A Python Inspiration

Using Python (on Windows), there’s a magical package that can be used to get all sorts of information about the system.

Without going into too much detail, it boils down to this: Say you want to list all the installed physical fans. You can do that using the following code:

import wmi
c = wmi.WMI()
for fan in c.Win32_Fan():
    if fan.ActiveCooling:
        print(f"Fan `{fan.Name}` is running at {fan.DesiredSpeed} RPM")

This uses a couple of clever __getattr__ implementations, and ends up running this equivalent code behind the scenes:

for fan in c.query("SELECT * FROM Win32_Fan"):
    if fan.wmi_property("ActiveCooling").value is True:
        print(f"Fan `{fan.wmi_property('Name').value}` is running at {fan.wmi_property('DesiredSpeed').value} RPM")

(The wmi_property method returns another object which holds the final value as well as its type.)

Putting aside what WMI even is, this is the kind of thing Python is extraordinarily good at: A clear, concise, and intuitive interface abstracting over a complex and gnarly implementation.

In Python, you need but override a few magic methods to implement this, but Rust is a completely different beast.

What can we do if we want to create a Rust crate that provides a nice API to users, similar to the one above?

What We Are Abstracting Over

It’ll help to start by expressing the “raw” API in pure Rust. It’s raw in the sense that we can use it to get the raw data from the system, but nothing more.

We have two types: the Value type that can hold different types of values, and the Object type that provides access to named attributes (which are themselves Value instances).

We end up with something like this (the full code is available on GitHub):

mod raw_api {
    pub struct Object { .. }

    pub enum Value {
        Bool(bool),
        I1(i8),
        // ..
        UI8(u64),
        String(String),
        Object(Object),
    }

    impl Object {
        pub fn get_attr(&self, name: &str) -> Value { .. }
    }

    pub fn query(query: &str) -> Vec<Object> { .. }
}

Simple, but rather painful for the user to work with:

let res = raw_api::query("SELECT * FROM Win32_Fan");

for obj in res {
    if obj.get_attr("ActiveCooling") == Value::Bool(true) {
        if let Value::String(name) = obj.get_attr("Name") {
            if let Value::UI8(speed) = obj.get_attr("DesiredSpeed") {
                println!("Fan `{name}` is running at {speed} RPM");
            }
        }
    }
}

Since any field can be of any type, the user must manually check (either with match or, as we did, with if let) what variant of the Value enum they got every time they interact with it.
This is especially cumbersome when one wants to query many different types of objects (Win32_Battery 🔋, Win32_UserAccount 💁, Win32_Printer 🖨️, …).

Gordon Ramsay yelling IT'S RAW

Note: this is a simplification of the underlying API we have to use, but it’s close enough that we can design our higher level API based on it. You can check the wmi-rs crate source code for the full details.

A Possible Design

Inspired by the Pythonic API, what if instead we could do something like this:

// 1. The user defines a custom struct for the type of objects to query.
struct Fan {
    name: String,
    active_cooling: bool,
    desired_speed: u64,
}

// 2. Specify that `query` should to return instances of `Fan`.
let res: Vec<Fan> = api::query();

// 3. Profit.
for fan in res {
    if fan.active_cooling {
        println!("Fan `{}` is running at {} RPM", fan.name, fan.desired_speed);
    }
}

Much nicer!

One of the distinct features of Rust is that generic return types can change the behavior of a function (with .collect() being the most famous example of this), so how can we implement something like this?

Imagine we went ahead and updated query to accept some generic type T. What trait can we use to constrain T so we can implement the function?

fn query<T>() -> Vec<T> where T: ??? { ??? }

The standard library offers any::type_name which could (not really) help us to build the SELECT query, but without resorting to violence, we seem to be on our own.

Crawl Before You Can Walk

Let’s start with a relatively simple solution: Let’s define a new trait that:

  1. Provides the name of the object to query.
  2. Handles the construction of e.g. Fans from Objects.

This will give us a firm ground to stand on before we dive deeper.

trait Queryable {
    fn object_name() -> &'static str;
    fn from(obj: Object) -> Self;
}

fn query<T: Queryable>() -> Vec<T> {
    let name = T::object_name();
    let mut res = vec![];

    for obj in raw_api::query(&format!("SELECT * FROM Win32_{name}")) {
        res.push(T::from(obj))
    }

    res
}

And once the user implements2 this new trait for Fan:

impl Queryable for Fan {
    fn object_name() -> &'static str {
        "Fan"
    }

    fn from(obj: Object) -> Self {
        let name = if let Value::String(name) = obj.get_attr("Name") {
            name
        } else {
            panic!()
        };

        // .. repeat for the other fields ..

        Fan {
            name,
            active_cooling,
            desired_speed,
        }
    }
}

Then they can use our improved query function by specifying the return type:

let res: Vec<Fan> = api::query();

Which is a substantial improvement over the raw_api:query version we had before.

While simpler to do from the library’s point of view, this approach forces the user to manually implement the Queryable trait for each and every new type they want to use, which is verbose and error-prone and not really ergonomic, even without proper error handling or support for nested objects.

We could use dtolnay’s guide and learn to write procedural macros, create a macro that generates this implementation automatically3 and expose it to users, but… we can use dtolnay’s serde which essentially does all of this already!

Serde to the Rescue

Serde is a framework for serializing and deserializing data in Rust, which means that it defines traits (Serialize and Deserialize), as well as the ability to use derive to generate implementations for these traits at compile time.

It is this ability to to generate a Deserialize implementation and than use it to create instances of a type that’s going to be useful to us.

I should preface this by saying that while we’ll learn a lot about the internals of Serde (which, fair warning, is a complex topic even when focusing on a specific part like we’ll do), I’m not trying to claim that this is the most conventional use case for Serde (see the Alternatives section for more about this). I do think the result is pretty neat though.

To use Serde, we usually need an additional library that leverages these traits to interact with different data formats.

For example, using serde_json looks like this for Fan:

use serde::Deserialize;

#[derive(Debug, Deserialize)]
#[serde(rename_all = "PascalCase")]
pub struct Fan {
    name: String,
    active_cooling: bool,
    desired_speed: u64,
}

let fan: Fan = serde_json::from_str(r#"{ "Name": "CPU1", "ActiveCooling": true, "DesiredSpeed": 1100 }"#)?;

println!("Fan `{}` is running at {} RPM", fan.name, fan.desired_speed);

Note: Already, using Serde begins to pay off: rename_all = "PascalCase" is just what we need to keep our field names in snake_case.

Since Serde is able to create the user’s struct (Fan) from different “data formats” (JSON, YAML, Postcard, …), we can pretend to be another data format, and hitch a ride on the compile-time generated Deserialize impl provided by derive(Deserialize).

If we can do that, we’ll be able to create a query function that accepts any struct that implements Deserialize, which would be convenient for our users: not only can they simply add derive(Deserialize) to their types, they also can use different Serde configurations (like the rename_all option) and the rich ecosystem around Serde (like the serde_with crate).

The bottom line is that we want to switch from our custom Queryable trait to Serde’s Deserialize trait, which would look a bit like this:

-fn query<T: Queryable>() -> Vec<T> { .. }
+fn query<T: Deserialize>() -> Vec<T> { .. }

Now, this is much easier said than done, so this might be a good time to get a fresh pot of tea or coffee: we have a long road ahead of us (with lots and lots of traits).

Note: If you’re less familiar with Rust, hold on to your whitespaces: this is where the deeper part of the deep dive starts, but feel free to go straight to the summary.

Peeking Under the Hood

We know that we want to use the Deserialize trait in our query function, but because it’s almost never implemented or used directly, we need to learn more about it before we can do that.

So, to get a better sense of how the code above works, let’s try to replace the derive(Deserialize) with a manual (and not feature complete)4 implementation of Deserialize for the Fan struct.

We’ll do this in a multiple stages, but it boils down to (1) defining new utility structs and then (2) implementing some traits for them.

We’ll start by looking at the definition of the Deserialize trait, and add an impl of it for Fan:

// The `Deserialize` trait:
pub trait Deserialize<'de> {
    fn deserialize<D>(deserializer: D) -> Result<Self, D::Error>
       where D: Deserializer<'de>;
}

// Our implementation:
impl<'de> serde::Deserialize<'de> for Fan { .. }

You can safely ignore the 'de lifetime for our use case (because we are not going to keep any data borrowed from the Deserializer), and read the implementation definition as:

For any lifetime 'de, this is the implementation of the serde::Deserialize trait (with that lifetime) for Fan.5

The only method we need to implement is fn deserialize, which accepts a Deserializer.
Again, you can safely ignore the 'de lifetime, but you can read D: serde::Deserializer<'de> as:

The generic type D implements the serde::Deserializer trait, and any borrowed data it may produce will have the 'de lifetime.

fn deserialize<D>(
    deserializer: D,
) ->  Result<Fan, D::Error>
where
    D: serde::Deserializer<'de> { .. }

Unexpectedly, most of the interesting code doesn’t live in the Deserialize impl at all6.

impl<'de> serde::Deserialize<'de> for Fan {
    fn deserialize<D>(
        deserializer: D,
    ) ->  Result<Self, D::Error>
    where
        D: serde::Deserializer<'de>,
    {
        const FIELDS: &'static [&'static str] = &[
            "Name",
            "ActiveCooling",
            "DesiredSpeed",
        ];

        deserializer.deserialize_struct(
            "Fan",
            FIELDS,
            // New type!
            FanVisitor {},
        )
    }
}

Let’s break this down a little.

The deserializer argument (which can be, for example, serde_json::Deserializer) is the part that knows how to access the data we need from the “data format” (the JSON-formatted string, in this case).

The Deserializer trait has a cosy 32 methods, but we are using just one: deserialize_struct.

trait Deserializer<'de> {
    type Error: Error;

    fn deserialize_struct<V>(
        self,
        name: &'static str,
        fields: &'static [&'static str],
        visitor: V,
    ) -> Result<V::Value, Self::Error>
       where V: Visitor<'de>;
}

The most interesting thing about this function is the Visitor argument.

Consider the point-of-view of the Deserializer, as it processes { .., "DesiredSpeed": 1100 }. What is the problem that is actually being solved here?

the FanVisitor is constructing a Fan, but it could be building a HashMap<String, i32>, or any number of different things.

All the deserializer knows is that it’s currently looking at a mapping, and that the current key is a string, while the value is some number.

It needs a way to tell us this, which is where the Visitor comes in: by defining our own FanVisitor, we’ll let the deserializer “drive” it by calling different methods on it for the data it sees, and FanVisitor will get to decide how to handle that data.

So our job is to give the deserializer a visitor it can use to feed data back to us. This is a bit confusing at first, but seeing it in action will help clear things up.

Technically, we can’t know exactly how the deserialize_struct function is going to be implemented by different deserializers for different inputs, but the serde_json deserializer calls visitor.visit_map for the example input above, so this is what we need to implement.

// Remember: `derive(Deserialize)` automatically generates this code
// (both new struct and the impl) at compile time, based on the `Fan` struct definition.

// A struct with no fields, only needed so we can attach the impl to something.
struct FanVisitor;
impl<'de> serde::de::Visitor<'de> for FanVisitor {

    // The visitor specify what type it is going to produce
    // (as indicated by the return type of `visit_map`).
    type Value = Fan;

    // The `map` is where the data from the deserializer is coming from.
    fn visit_map<A>(self, mut map: A) -> Result<Self::Value, A::Error>
    where
        A: serde::de::MapAccess<'de>,
    {
        let (mut name, mut active_cooling, mut desired_speed) = (None, None, None);

        // Use the `map` we got from the deserializer.
        // `key`'s type is `&str`, which means we call `map.next_key::<&str>()`.
        while let Ok(Some(key)) = map.next_key() {
            // But, `next_value()` returns different types for different fields.
            // We'll explain how later, when we implement our own `Deserializer` and `MapAccess`.
            match key {
                "Name" => {
                    let val: String = map.next_value()?;
                    name = Some(val);
                }
                "ActiveCooling" => {
                    let val: bool = map.next_value()?;
                    active_cooling = Some(val);
                }
                // ..
            }
        }

        Ok(Fan { .. })
    }
}

We’ll dive deeper into the MapAccess trait in the next section, but notice for now that we use it to get both keys and values, and that we (the Visitor) determine what types they should be (or rather, what type they should be deserialized into).

There are various other visit_{u64,string,bool,...} functions, but by default they simply return an error, so we can implement only visit_map for this minimal example.

Having done this, the same code from before can now work without the derive(Deserialize):

pub struct Fan { .. }
impl<'de> serde::Deserialize<'de> for Fan { .. }

let fan: Fan = serde_json::from_str(r#"{ "Name": "CPU1", "ActiveCooling": true, "DesiredSpeed": 1100 }"#)?;

println!("Manual Serde impl: Fan `{}` is running at {} RPM", fan.name, fan.desired_speed);

So, let’s recap what we know about the trait-zoo of Serde:

  1. Deserialize::deserialize accepts a Deserializer, and calls (for a struct like Fan) the deserializer.deserialize_struct function, with a Visitor (like FanVisitor), which handles the creation of the struct.

  2. The Deserializer (in this case serde_json::Deserializer) calls a visitor.visit_ function (in this case, visit_map), which provides data from the Deserializer (in this case, a map which implements MapAccess).

  3. The Visitor now calls the map’s next_{key,value} functions which return the data needed to build the struct.

  4. Once there is no next_key in the map, the Visitor finishes and returns the created value (in this case, an instance of Fan).

Or, more visually:

let fan = Fan::Deserialize(serde_json::Deserializer::from_str(r#"{ "Name": "CPU1", "Active.."#));

impl Deserialize for Fan                            impl Deserializer for serde_json::Deserializer
 fn deserialize(deser)
   let visitor = FanVisitor {}
   deser.deserialize_struct(.., visitor) calls──►  fn deserialize_struct(.., visitor)
                                                      let map = serde_json::de::MapAccess::new(..)
   impl Visitor for FanVisitor
    fn visit_map(map) ◄────────calls───────────────── return visitor.visit_map(map)
      loop {                                          impl MapAccess for serde_json::de::MapAccess
        key = map.next_key() ──────calls────────────►  fn next_key()   // { ..,▼"Name": ..
        /* since key is "Name" */
        name: String = map.next_value() ───calls────►  fn next_value() // {         ..:▼"CPU1", ..
      }
◄────── return Fan { ... }

Well, “more” being a key word here.

Charlie Conspiracy (always Sunny In Philadelphia)

Now that we have a basic understanding of the flow let’s leave the manual Deserialize impl and it’s FanVisitor behind us, and focus on our actual goal: a better query API.

-pub struct Fan { .. }
-impl<'de> serde::Deserialize<'de> for Fan { .. }
+#[derive(Debug, Deserialize)]
+#[serde(rename_all = "PascalCase")]
+pub struct Fan { .. }

Implementing a Deserializer

The reason we opt to use Deserialize was because Serde can derive it for the user’s type. So our job is to implement the query function in a way that:

  1. Accepts T that implements Deserialize.
  2. Create Ts from raw_api::Objects by calling their Deserialize::deserialize function.

Since we now know much more about what the Deserialize::deserialize function does, let’s go ahead and start by updating query to use Deserialize, with a small twist:

pub fn query<T: DeserializeOwned>() -> Vec<T> {
    // We'll fix this one later.
    let name = "Fan";
    let mut res = vec![];

    for obj in raw_api::query(&format!("SELECT * FROM Win32_{name}")) {
        // New type!
        let deser = ObjectDeserializer { obj };
        res.push(T::deserialize(deser).unwrap())
    }

    res
}

Instead of using Deserialize<'de>, we use DeserializeOwned, which is similar but forbids users from using types that borrow data (like struct BorrowedFan<'a> { name: &'a str }).7

The main difference between this and our Queryable trait version is that Serde introduces a new intermediary struct and trait (T::deserialize(ObjectDeserializer { obj }) vs T::from(obj)): the added level of indirection is what allows us to decouple the Deserializer from the user’s T.

Serde’s docs describe implementing a deserializer like so:

The deserializer is responsible for mapping the input data into Serde’s data model by invoking exactly one of the methods on the Visitor that it receives.
The Deserializer methods are called by a Deserialize impl as a hint to indicate what Serde data model type the Deserialize type expects to see in the input.

Similar to our custom implementation, the derive(Deserialize) version is also going to call deserialize_struct, so we need to implement that:

struct ObjectDeserializer {
    obj: raw_api::Object,
}

impl<'de> Deserializer<'de> for ObjectDeserializer {
    // .. snip ..
    // There are all sorts of `deserialize_{bool,str,enum,...}`,
    // but we can ignore them for now since we only want to support `struct`s.

    // Our implementation, which will be called by `T::Deserialize`:
    fn deserialize_struct<V>(
        self,
        name: &'static str,
        fields: &'static [&'static str],
        visitor: V,
    ) -> Result<V::Value, Self::Error>
    where
        V: serde::de::Visitor<'de>,
    {
        todo!()
    }
}

Given all that we’ve seen so far, our deserialize_struct method will need to:

  1. Define a new struct that implements serde::de::MapAccess.
  2. Call visitor.visit_map with that struct, which will need return the right keys and values every time next_key and next_value are called.

Implementing the MapAccess trait requires only two functions: next_key_seed and next_value_seed. They are very similar to next_{key,value} we called before, but with some additional flexibility provided by DeserializeSeed, which I’ll get to in a bit.

trait MapAccess<'de> {
    type Error: Error;

    fn next_key_seed<K>(&mut self, seed: K) -> Result<Option<K::Value>, Self::Error>
       where K: DeserializeSeed<'de>;

    fn next_value_seed<V>(&mut self, seed: V) -> Result<V::Value, Self::Error>
       where V: DeserializeSeed<'de>;

    // ..
}

So we need to return each of the fields as the key in next_key_seed, and then return the field’s value in the following call to next_value_seed.

We can define a new struct called ObjectMapAccess and use it like this:

struct ObjectMapAccess {
    // Nothing fancy, this is the type that we get
    // by calling `fields.iter().peekable()`.
    fields: Peekable<Iter<'static, &'static str>>,
    obj: raw_api::Object,
}

// in deserialize_struct's body:
let map = ObjectMapAccess {
    fields: fields.iter().peekable(),
    obj: self.obj,
};

visitor.visit_map(map)

The basic logic in the implementation of MapAccess for ObjectMapAccess is to peek() the next field from fields in next_key_seed, then get it again via next() in the next_value_seed and call obj.get_attr on it.

But if we do this and look at the signatures of both functions, we’ll see we aren’t done yet:

impl<'de> serde::de::MapAccess<'de> for ObjectMapAccess {
    fn next_key_seed<K>(&mut self, seed: K) -> Result<Option<K::Value>, Self::Error>
    where
        K: serde::de::DeserializeSeed<'de>,
    {
        if let Some(field) = self.fields.peek() {
            // Hmm.
        } else {
            Ok(None)
        }
    }

    fn next_value_seed<V>(&mut self, seed: V) -> Result<V::Value, Self::Error>
    where
        V: serde::de::DeserializeSeed<'de>,
    {
        let current_field = self.fields.next().unwrap();

        let field_value = self.obj.get_attr(current_field);

        // Hmm.
    }
}

Bad Seeds

The problem is that if we look at the return types for both functions, we need to return K::Value and V::Value, but we only know that K and V implement DeserializeSeed, which looks like this in comparison to Deserialize:

trait Deserialize<'de> {
    fn deserialize<D>(deserializer: D) -> Result<Self, D::Error>
       where D: Deserializer<'de>;
}

trait DeserializeSeed<'de> {
    // New.
    type Value;

    // Return type uses `Value`.
    fn deserialize<D>(self, deserializer: D) -> Result<Self::Value, D::Error>
       where D: Deserializer<'de>;
}

Don’t worry about it too much, but roughly speaking it means that a DeserializeSeed value can have some state (vs. the regular Deserialize which cannot).

When a visitor calls let name: String = map.next_value().unwrap(), for example, the type substitution results in:

fn next_value_seed(
    &mut self,
    seed: PhantomData<String>,
) -> Result<String, Self::Error> { ... }

and calling seed.deserialize(..) is equivalent to calling String::deserialize(..).

Note: PhantomData is Rust-speak for “I care about the type of something, but don’t have actual value of that type”.

With that out of the way, we can now finally complete the trait puzzle!

It’s Deserializers All the Way Down

The only thing we can do is to call seed.deserialize on something that is a Deserializer, since it’s the only function provided by the Deserialize/DeserializeSeed traits.

For the field name, this turns out to be easy: we know the field name we have is a &str, and Serde provides a StrDeserializer which (as the name suggests) implements the Deserializer trait, and can be created from a &str.

Using the same visualization from before, if the calling Visitor expects a String key (for example in HashMap<String, _>), we’ll get something like this:

// Same as `next_key_seed` after type substitution for `String`:
// `StrDeserializer` is defined as `struct StrDeserializer { value: &str, .. }`.
fn next_key() -> Result<String, _> { String::deserialize(StrDeserializer::new("Name")) }
let key: String = next_key();

impl Deserialize for String                        impl Deserializer for StrDeserializer
 fn deserialize(deser)
   let visitor = StringVisitor {}
   deser.deserialize_string(.., visitor) calls─►  fn deserialize_string(.., visitor)
                                                      let value = self.value
   impl Visitor for StringVisitor
    fn visit_str(value: &str) ◄────────calls──────── return visitor.visit_str(value)
◄────── return Ok(value.to_owned())

You can also think about this as the “base case” for the Visitor: somewhere down the stack, we’ll want to construct some primitive type which has a Deserialize implementation that doesn’t recurse any further.

This might seem a bit over the top in this case, but remember that visit_map needs to support any key type that can be deserialized (like when building a HashMap<i32, i32> from JSON - playground).

Putting all of this together, we arrive at this implementation of next_key_seed:

if let Some(field) = self.fields.peek() {
    // Create a `StrDeserializer` for the &str.
    let field_deser = StrDeserializer::new(field);

    // Let the seed use the deserializer's data to create whatever type it needs.
    // `StrDeserializer` will call `visitor.visit_str(field)`
    // on whatever visitor is defined by the seed's impl.
    // For structs, the `derive` generates an `enum Fields { .. }`,
    // which will pick the right variant based on the provided &str.
    seed.deserialize(field_deser).map(Some)
} else {
    Ok(None)
}

Now, as we turn to next_value_seed, the solution is obvious: we need another struct, and we need that struct to implement the Deserializer trait for raw_api::Value:

struct ValueDeserializer { value: raw_api::Value }

let current_field = self.fields.next().unwrap();
let field_value = self.obj.get_attr(current_field);

seed.deserialize(ValueDeserializer { value: field_value })

Before, when we implemented Deserializer for ObjectDeserializer, we didn’t have what Serde calls “a self-describing data format”: we needed the hint from deserialize_struct’s fields parameter to know what data to get using the get_attr function.

This time, raw_api::Value is actually a self-describing data format: it knows exactly which function of the visitor to call:

impl<'de> Deserializer<'de> for ValueDeserializer {
    fn deserialize_any<V>(self, visitor: V) -> Result<V::Value, Self::Error>
    where
        V: Visitor<'de> {
        match self.value {
            raw_api::Value::Bool(b) => visitor.visit_bool(b),
            raw_api::Value::I1(v) => visitor.visit_i8(v),
            // ..
            raw_api::Value::UI8(v) => visitor.visit_u64(v),
            raw_api::Value::String(s) => visitor.visit_string(s),
            _ => todo!(),
        }
    }

    // Because this is common, Serde provides this macro that makes other
    // `deserialize_` functions use the `deserialize_any` we implemented.
    forward_to_deserialize_any! {
        bool i8 i16 i32 i64 i128 u8 u16 u32 u64 u128 f32 f64 char str string
        bytes byte_buf option unit unit_struct newtype_struct seq tuple
        tuple_struct map enum struct identifier ignored_any
    }
}

Crossing our fingers, we can update the query call:

use serde::Deserialize;

#[derive(Debug, Deserialize)]
#[serde(rename_all = "PascalCase")]
pub struct Fan { .. }

let res: Vec<Fan> = query();

for fan in res {
    if fan.active_cooling {
        println!(
            "Fan `{}` is running at {} RPM",
            fan.name, fan.desired_speed
        );
    }
}

Recompile and…

$ cargo run
Fan `CPU1` is running at 150 RPM

everything compiles and works as expected! Huzza!

Recap

To recap, the final flow is:

  1. User calls query with a T that implements Deserialize.
  2. Query fetches the objects, and calls T::Deserialize with our ObjectDeserializer.
  3. T::Deserialize calls ObjectDeserializer::deserialize_struct with T’s unique compile-time generated Visitor, like the FanVisitor we implemented.
  4. ObjectDeserializer::deserialize_struct creates an ObjectMapAccess, and passes it to T’s Visitor.
  5. T’s Visitor calls the map’s next_key and next_value to build a new instance of T.
  6. next_key returns a field name from the peekable iterator, followed by next_value which calls get_attr to get the Value of that field.
  7. We create a new ValueDeserializer with the field’s Value, and passes it to the seed’s Deserialize (which is the Deserialize impl of String, then bool, and finally of u64).
  8. String’s Deserialize calls ValueDeserializer::deserialize_string, which is forwarded to deserialize_any, which calls visitor.visit_string(s), which is handled by String’s Deserialize’s Visitor.
  9. String’s Deserialize’s Visitor only needs to return the s it got from that call.
  10. Finally, after doing this for each field, T’s Visitor is done and returns a new instance of T.

You can also check the full code, which is less than 150 lines, in the v2_api.rs file on GitHub.

As a bonus point, consider that this is pretty much a zero overhead abstraction: we are doing almost exactly what the manual Queryable implementation did, with a few more indirections that can be optimized away by the compiler.

Summary

So what did we learn today?

We saw how to use Rust’s trait system to build interesting and ergonomic APIs, and we explored Serde’s internals and its unique set of traits and used them to overcome some of the difficulties we had when using only custom traits to build our API.

We saw that while there are a lot of things going on behind the scenes, Serde doesn’t rely on magic - it’s built on a creative and sophisticated use of Rust’s powerful trait system.

Before paying off one final debt and showing how we can get the name of T, let’s wrap up by talking about some alternatives and tradeoffs.

Alternatives

This is far from the only way to do this: building a procedural macro is perhaps the more “classic” solution to this problem, and while for me the tradeoffs between maintainability, feature support, and ease of use still justify the use/abuse of Serde, I still think there’s room for a middle ground (perhaps like dtolnay’s reflect).

On the other end of the spectrum, it’s also possible to lean into code generation, like the tonic and prost crates do for dealing with ProtoBufs and gRPC clients and servers. WMI also supports an RPC-like interface for method calling, and a first-class support for it would probably require something similar. Again, it’s all about the tradeoffs: focusing on data queries makes it harder to justify the added complexity (both in implementation for the library and in usage for users).

There are also different ORM-oriented crates that might be a good fit for this use case (especially since we could also benefit from generating the SQL-like queries from typed objects), but at the time the ecosystem was a lot less developed, and also much less stable: in more than 7 years, Serde’s API didn’t break once (still on version 1), while the ORM ecosystem changed a lot since.

I think it would also be interesting to see how a different approach to compile-time code generation, like Zig’s comptime, can support something similar.

Future Work

You can explore the entire source code for this article in this GitHub repo, or check the code of the wmi-rs crate, which also has:

  1. Nested objects support, like struct Win32_DiskDriveToDiskPartition { Antecedent: Win32_DiskDrive, Dependent: Win32_DiskPartition }.
  2. New-type support and HashMap support, like struct Fan(HashMap<String, Value>).
  3. Enum support, like enum CIM_CoolingDevice { Win32_Fan(Fan), Win32_HeatPipe(HeatPipe), .. }.
  4. Deserialization of chrono and time objects from strings (using struct WMIDateTime(pub DateTime<FixedOffset>) with a custom deserializer).
  5. Serialization support (like creating an Object from Fan).

(and, obviously, an implementation of the “raw” API for using Windows’ WMI infrastructure).

Going a Step Further

Remember this:

pub fn query<'de, T>() -> Vec<T>
where
    T: Deserialize<'de>,
{
    // We'll fix this one later.
    let name = "Fan";

    // ..
}

Well, we saw that the deserialize_struct function we implemented accept both the fields argument (which we used), and also the name argument.

But… we can’t use that since we don’t have an Object to deserialize yet.

The answer? You guessed it! Yet another struct and a Deserializer impl, this time taken directly from Serde issue #1110:

// A new `Deserializer` that can write the `struct`'s name
// to a caller's variable.
struct StructNameDeserializer<'a> {
    name: &'a mut Option<&'static str>,
}

impl<'de, 'a> Deserializer<'de> for StructNameDeserializer<'a> {
    fn deserialize_struct<V>(
        self,
        name: &'static str,
        fields: &'static [&'static str],
        visitor: V,
    ) -> Result<V::Value, Self::Error>
    where
        V: Visitor<'de>,
    {
        // Store the name.
        *self.name = Some(name);
        self.deserialize_any(visitor)
    }

    // Always end with an error, since we don't want to deserialize anything.
    fn deserialize_any<V>(self, _visitor: V) -> Result<V::Value, Self::Error>
    where
        V: Visitor<'de>,
    {
        Err(de::Error::custom("I'm just here for the metadata"))
    }

    // .. snip ..
}

let mut name = None;

let _ = T::deserialize(StructNameDeserializer {
    name: &mut name,
});

Since T’s Deserialize impl will call deserialize_struct with the struct’s name, our deserializer will capture that name and write it back to the given name variable, then end with an error (that is ignored by the caller).

One neat feature we get for free here is that using #[serde(rename = "..")] on the struct works as you might expect:

#[derive(Default, Deserialize)]
#[serde(rename = "Fan")]
#[serde(rename_all = "PascalCase")]
pub struct OsFan {
    name: String,
    active_cooling: bool,
    desired_speed: u64,
}

assert_eq!(struct_name::<OsFan>(), "Fan");

  1. The result of this work is the wmi-rs crate, which I maintain to this day. ↩︎

  2. Our new trait is essentially From<Object> with the small addition of returning the name of the object to query, so a more idiomatic definition would be trait Queryable: From<Object> { .. } which requires two separate implementations. ↩︎

  3. And we didn’t mention casing conversions (ActiveCooling vs active_cooling), struct name customizations (What if the user want the struct to be struct SystemFan {}?), safe integer conversions (f1: u64 should - or maybe should not - accept a u8 value?), enum support, and so much more! ↩︎

  4. You can use cargo expand to see what derive(Deserialize) does, but it’s too verbose to really be educational. You can view it here in the playground↩︎

  5. We can also say that the 'de lifetime is an unconstrained lifetime parameter. Contrast this with Serde’s impl<'de: 'a, 'a> Deserialize<'de> for &'a str, which can be read as “For any lifetime 'de that’s longer than 'a, ..”, and BorrowedStrDeserializer, which holds a &'de str and only impl<'de> de::Deserializer<'de> for BorrowedStrDeserializer<'de>↩︎

  6. Ok, technically, in the derive(Deserialize) impl, both Visitor and impl de::Visitor are defined inside the deserialize method, but I think the point stands. ↩︎

  7. Compare and contrast to serde_json::from_str and serde_json::from_reader↩︎
